Using BIOS

System Component Characteristics

These items display the monitoring of the overall inboard hardware health events,

such as System & CPU temperature, CPU & DIMM voltage, CPU & system fan

speed,...etc.

• CPU Temperature

• NB Temperature

• System Temperature

• CPU Fan Speed

• PWR Fan Speed

• System FAN Speed

• CPU Vcore

• Vcc NB

• Vcc SB

• VDIMM

• VBAT

Press <Esc> to return to the Smart Fan Function page.

DeltaT1 (+3)

SMART Fan Slope PWM value (3 PWM value/°C)

Press <Esc> to return to the main menu setting page.

Shutdown Temperature (CPU) (Disabled)

Enable you to set the maximum temperature the CPU can reach before powering

down

This item specifies the range that controls CPU temperature and keeps it from going

so high or so low when smart fan works.

This item is used to set the Slope Select PWM of the smart fan.

SMART Fan start PWM value (28)

SMART Fan start TEMP. (°C) (27)

This item is used to set the start PWM value of the smart fan.

This item is used to set the start temperature of the smart fan.

CPU FAN Full Limit Temp. (65°C)

This item is used to set the Slope Select PWM of the smart fan.

PWR Fan Control (Disabled)

This item allows you to enable or disable the control of the power fan.

System Fan Control (Disabled)

This item allows you to enable or disable the control of the system fan speed

bychanging the fan voltage.

Shutdown Temperature (NB) (Disabled)

Enable you to set the maximum NB temperature the system can reach before pow-

ering down.
