ECS A785GM-M User Manual

39
Using BIOS
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
SMART FAN Control Enabled
Smart Fan Mode Quiet
SMART Fan start PWM value. 20
SMART Fan start TEMP. (°C) 52
DeltaT1 +3
SMART Fan Slope PWM value 8 PWM value/°C
CPU FAN Full Limit Temp. 65°C
PWR Fan Control Disabled
System Fan Control Disabled
Normal: auto adjusts
depending on the CPU
temperature
F10: Save ESC: Exit+/-/: Value
Enter : Select
F1:General Help
: Move
mnlk
Options
F9: Optimized Defaults
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
SMART FAN Control Enabled
Smart Fan Mode Silent
SMART Fan start PWM value. 5
SMART Fan start TEMP. (°C) 60
DeltaT1 +3
SMART Fan Slope PWM value 14 PWM value/°C
CPU FAN Full Limit Temp. 68°C
PWR Fan Control Disabled
System Fan Control Disabled
F10: Save ESC: Exit+/-/: Value
Enter : Select
F1:General Help
: Move
mnlk
Options
F9: Optimized Defaults
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
SMART FAN Control Enabled
Smart Fan Mode Manual
SMART Fan start PWM value. 5
SMART Fan start TEMP. (°C) 60
DeltaT1 +3
SMART Fan Slope PWM value 14 PWM value/°C
CPU FAN Full Limit Temp. 68°C
PWR Fan Control Disabled
System Fan Control Disabled
F10: Save ESC: Exit+/-/: Value
Enter : Select
F1:General Help
: Move
mnlk
Options
F9: Optimized Defaults
Quiet: auto minimizes
fan speed for quiet
environment operation
Normal: auto adjusts
depending on the CPU
temperature
Quiet: auto minimizes
fan speed for quiet
environment operation
Normal: auto adjusts
depending on the CPU
temperature
Quiet: auto minimizes
fan speed for quiet
environment operation

ECS A785GM-M Specifications

General

Number of memory slots	4
Maximum internal memory	32 GB
Processor socket	Socket AM3
Processor manufacturer	AMD
USB 2.0 connectors	3
Power fan connector	Yes
Number of COM connectors	1
Number of SATA connectors	6
Controller interface type	AMD SB710
PS/2 ports quantity	0
eSATA ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC888S
Power source type	ATX
Motherboard chipset	AMD 785G
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
BIOS type	AMI
RAID levels	0, 1
LAN controller	RealTek RTL8111D(L)
