Page #29 background imageLoading...
Page #29 background image
25
Installing the Motherboard
PWR_FAN: FAN Power Connectors
Pin Signal Name Function
1 GND System Ground
2 +12V Power +12V
3 Sense Sensor
ATX12V: ATX 12V Power Connector
Pin Signal Name
4 Ground
3 Ground
2 Ground
1 Ground
Pin Signal Name
5 +12V
6 +12V
7 +12V
8 +12V
ATX_POWER: ATX 24-pin Power Connector
1 +3.3V 13 +3.3V
2 +3.3V 14 -12V
3 Ground 15 COM
4 +5V 16 PS_ON
5 Ground 17 COM
6 +5V 18 COM
7 Ground 19 COM
8 PWRGD 20 -5V
9 +5VSB 21 +5V
10 +12V 22 +5V
11 +12V 23 +5V
12 +3.3V 24 COM
Pin Signal Name Pin Signal Name

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ECS A785GM-M and is the answer not in the manual?

ECS A785GM-M Specifications

General IconGeneral
Number of memory slots4
Maximum internal memory32 GB
Processor socketSocket AM3
Processor manufacturerAMD
USB 2.0 connectors3
Power fan connectorYes
Number of COM connectors1
Number of SATA connectors6
Controller interface typeAMD SB710
PS/2 ports quantity0
eSATA ports quantity2
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chipRealtek ALC888S
Power source typeATX
Motherboard chipsetAMD 785G
Audio output channels7.1 channels
Motherboard form factormicro ATX
BIOS typeAMI
RAID levels0, 1
LAN controllerRealTek RTL8111D(L)
