Chapter 3
H61H2-I3 USER MANUAL
33
The Advanced menu items allow you to change the settings for the CPU and other
system.
Advanced Menu
LAN Configuration
The item in the menu shows the LAN-related information that the BIOS
automatically detects.
Onboard LAN Controller (Enabled)
Use this item to enable or disable Onboard LAN 1 controller.
Network stack (Enabled)
Use this item to enable or disable UEFI network stack.
Ipv4/6 PXE Support (Enabled)
Use these items to enable or disable the Ipv4/6 PXE Boot support. If disabled IPV4/
6 PXE boot option will not be created.
Press <Esc> to return to the Advanced Menu page.
LAN Configuration Parameters
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
LAN Configuration
PC Health Status
Power Management Setup
ACPI Settings
CPU Configuration
SATA Configuration
USB Configuration
Super IO Configuration
Trusted Computing
Intel(R) Smart Connect Technology
Enabled/Disabled Onboard
LAN 1 Controller
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
LAN Configuration
Onboard LAN Controller Enabled
Network stack Enabled
Ipv4 PXE Support Enabled
Ipv6 PXE Support Enabled
