ECS H61H2-I3 User Manual

Chapter 3
H61H2-I3 USER MANUAL
34
CPU Smart Fan Control (Enabled)
This item allows you to enable/disable the control of the CPU fan speed by changing
the fan voltage.
SMART Fan Mode (Normal)
This item allows you to select the fan mode (Normal, Quiet, Silent, or Manual) for a
better operation environment. If you choose Normal mode, the fan speed will be
auto adjusted depending on the CPU temperature. If you choose Quiet mode, the
fan speed will be auto minimized for quiet environment. If you choose Silent mode,
the fan speed will be auto restricted to make system more quietly. If you choose
Manual mode, the fan speed will be adjust depending on users’ parameters.
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Scroll to this item and press <Enter> to view the following screen:
 Smart Fan Function
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
lk
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Smart Fan Function
PC Health Status
mn
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
CPU Fan Speed : 0 RPM
CPU Voltage : 1.056V
DIMM Voltage : 1.524V
CPUVTT Voltage : 1.056V
-=- PECI Mode -=-
Offset to TCC Activation Temp. : -61
CPU Smart Fan Control Enabled
SMART Fan Mode Normal
SMART Fan start PWM value 180
SMART Fan start PWM TEMP(-) 30
Delta T +3
SMART Fan Slope PWM value 10 PWM value/unit
CPU Fan Full Speed Offset (-) 23
