ECS H61H2-I3 User Manual

Chapter 3
H61H2-I3 USER MANUAL
51
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have
installed in your system.
M.I.B III (MB Intelligent BIOS III) Menu
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
lk
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
ESC/Right Click: Exit
F4: Save & Exit
mn
M.I.B III (MB Intelligent BIOS III)
CPU OverClocking Configuration
Chipset OverClocking Configuration
B.O.M.P Technology Enabled
Auto Detect DIMM/PCI Clk Enabled
Spread Spectrum Enabled
Intel(R) Core(TM) i7-3770K CPU @ 3.50GHz
Processor Speed 3500 MHz
Memory Frequency 1333 MHz
Total Memory 8192 MB (DDR3)
Integrated Clock Chip
Parameters
 CPU OverClocking Configuration
Scroll to this item to view the following screen:
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
lk
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
ESC/Right Click: Exit
mn
Enhanced Intel SpeedStep
Technology
F4:Save & Exit
CPU OverClocking Configuration
CPU Frequency 100
CPU Ratio 35
Enhanced Intel SpeedStep Technology Enabled
Turbo Mode Enabled
Internal PLL OverVoltage Disabled
Runtime Turbo Enable Disabled
Over Clocking Extra Vol.(1/256 V) 0
IA Core Current Maximum
iGFX Core Current Maximum
Long Duration Power Limit Override Maximum
Long Duration Maintained 10
Short Duration Power Limit Override Maximum
Intel Graphics Configuration
Graphics Core Ratio Limit 23
Graphics Voltage(1/256) 0
