H61H2-I3 USER MANUAL
2
CPU
Specifications
• AMI BIOS with 64Mb SPI Flash ROM
- Supports ECS M.I.B III Utility
- Supports Multi-Language BIOS Utility
System BIOS
• Intel
®
H61 Chipset
Chipset
• Dual-channel DDR3 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to 16 GB
• Supports DDR3 1600/1333/1066 MHz DDR3 SDRAM
Memory
• 1 x PCI Express x1 slot
• Supported by Intel
®
H61 Express Chipset
- 4 x Serial ATA 3.0Gb/s devices
Expansion
Slots
Storage
• 1 x 24-pin ATX Power supply connector
• 1 x 4-pin ATX Power supply connector
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector
• 2 x USB 2.0 headers support additional four USB 2.0 ports
• 4 x Serial SATA 3.0Gb/s connectors
• 1 x COM header
• 1 x ME_UNLOCK header
• 1 x Clear CMOS jumper
• 1 x Front Panel USB power select jumper
• 1 x Rear USB/PS2 power select jumper
• 1 x Case open header
• 1 x Front Panel switch/LED header
• 1 x Front Panel audio header
• 1 x TPM header
• 1 x Speaker header
• 1 x PS/2 keyboard & PS/2 mouse connectors
• 4 x USB 2.0 ports
• 1 x D-sub (VGA) port
• 1 x HDMI port (Co-lay DVI port)
• 1 x RJ45 LAN connector
• 1 x Audio port (line in, microphone in, line out)
Rear Panel I/O
LAN
• Realtek RTL 8111E Gigabit LAN Fast Ethernet Controller
• Realtek RTL 8105E 10/100 LAN (Optional)
• VIA VT1705 6-Ch High Definition audio CODEC
- Compliant with HD audio specification
Audio
• LGA1155 socket for Intel
®
Sandy/Ivy Bridge Processors
• DMI 5.0GT/s
• TDP: 65W
Internal I/O
Connectors &
Headers
Note: Please go to ECS website for the latest CPU support list.
Note: Please go to ECS website for the latest Memory support list.
