H61H2-I3 USER MANUAL
Chapter 1
5
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Socket LGA1155 socket for Intel® Sandy/Ivy Bridge Processors
2. CPU_FAN 4-pin CPU cooling fan connector
3. SYS_FAN 3-pin system cooling fan connector
4. DDR3_1~2 240-pin DDR3 Module slots
5. ATX_POWER Standard 24-pin ATX power connector
6. USBPWR_F Front Panel USB power select jumper
7. F_USB1~2 Front panel USB 2.0 headers
8. F_PANEL Front panel switch/LED header
9. SATA1~4 Serial ATA 3.0 Gb/s connectors
10. CASE Case open header
11. CLR_CMOS Clear CMOS jumper
12. ME_UNCLOCK ME Unlock header-for factory use only
13. SPK Speaker header
14. PCIE1 PCI Express x1 slot
15. TPM Trusted platform moudle header
16. F_AUDIO Front panel audio header
17. BT Battery connector
18. USBPWR_R Rear USB/PS2 power select jumper
19. COM Onboard serial port header
20. ATX12V 4-pin +12V power connector
