Using BIOS
Integrated Peripherals
These options display items that define the operation of peripheral components on the
system’s input/output ports.
SIS OnChip IDE Device [Press Enter]
SIS OnChip PCI Device [Press Enter]
Onboard SuperIO Device [Press Enter]
IDE HDD Block Mode [Enabled]
Init Display First [PCI Slot]
f
f
f
f
Phoenix-AwardBIOS CMOS Setup Utility
Integrated Peripherals
Item Help
Menu Level
fSIS OnChip IDE Device
Scroll to this item and press <Enter> to view the following screen:
Internal PCI/IDE (Both)
Use these items to enable or disable the internal PCI IDE channels that are integrated on the
motherboard.
IDE Primary/Secondary Master/Slave PIO (Auto)
Each IDE channel supports a master device and a slave device. These four items let you
assign the kind of PIO (Programmed Input/Output) was used by the IDE devices. Choose
Auto to let the system auto detect which PIO mode is best, or select a PIO mode from 0-4.
IDE Primary/Secondary Master/Slave UltraDMA (Auto)
Each IDE channel supports a master device and a slave device. This mainboard supports
UltraDMA technology, which provides faster access to IDE devices.
If you install a device that supports UltraDMA, change the appropriate item on this list to
Auto. You may have to install the UltraDMA driver supplied with this mainboard in order to
use an UltraDMA device.
Phoenix-AwardBIOS CMOS Setup Utility
SIS OnChip IDE Device
Item Help
Menu Level
ff
Internal PCI/IDE [Both]
IDE Primary Master PIO [Auto]
IDE Primary Slave PIO [Auto]
IDE Secondary Master PIO [Auto]
IDE Secondary Slave PIO [Auto]
Primary Master UltraDMA [Auto]
Primary Slave UltraDMA [Auto]
Secondary Master UltraDMA [Auto]
Secondary Slave UltraDMA [Auto]
IDE DMA transfer access [Enabled]
IDE Burst Mode [Enabled]
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
mnlk
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
mnlk
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
