Using BIOS
PNP/PCI Configurations
These options configure how PnP (Plug and Play) and PCI expansion cards operate in your
system. Both the ISA and PCI buses on the motherboard use system IRQs (Interrupt
ReQuests) and DMAs (Direct Memory Access). You must set up the IRQ and DMA assign-
ments correctly through the PnP/PCI Configurations Setup utility for the motherboard to
work properly. Selecting PnP/PCI Configurations on the main program screen displays this
menu:
Reset Configuration Data (Disabled)
If you enable this item and restart the system, any Plug and Play configuration data stored
in the BIOS Setup is cleared from memory.
Resources Controlled By (Auto(ESCD))
You should leave this item at the default Auto(ESCD). Under this setting, the system
dynamically allocates resources to Plug and Play devices as they are required.
Reset Configuration Data [Disabled]
Resources Controlled by [Auto (ESCD)]
IRQ Resources [Press Enter]
PCI/VGA Palette Snoop [Disabled]
INT Pin 1 Assignment [Auto]
INT Pin 2 Assignment [Auto]
INT Pin3 Assignment [Auto]
INT Pin4 Assignment [Auto]
INT Pin5 Assignment [Auto]
INT Pin6 Assignment [Auto]
INT Pin7 Assignment [Auto]
INT Pin8 Assignment [Auto}
Default is Disabled. Select
Enabled to reset Extended
System Configuration Data
ESCD) when you exit Setup
if you have installed a new
add-on and the system
reconfiguration has caused
such a serious conflict that
the OS cannot boot
Phoenix-AwardBIOS CMOS Setup Utility
PnP/PCI Configurations
Item Help
f
Menu Level
mnlk
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
If you cannot get a legacy ISA (Industry Standard Architecture) expansion card to work
properly, you might be able to solve the problem by changing this item to Manual, and
then opening up the IRQ Resources submenu.
