ECS Motherboard

38
Using BIOS
SIS 10/100M ETHERNET (Enabled)
This option allows you to control the onboard LAN.
SiS Serial ATA Controller (Enabled)
This item allows you to control the SiS Serial ATA controller.
SiS Serial ATA Mode (IDE)
This item allows you to change SiS Serial ATA mode.
Press <Esc> to return to the Integrated Peripherals screen.
fOnboard SuperIO Device
Scroll to this item and press <Enter> to view the following screen:
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
Onboard FDC Controller [Enabled]
Onboard Serial Port1 [3F8/IRQ4]
Onboard Parallel Port [378/IRQ7]
Parallel Port Mode [ECP]
ECP Mode Use DMA [3]
Phoenix-AwardBIOS CMOS Setup Utility
Onboard SuperIO Device
Item Help
ff
Menu Level
mnlk
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Onboard FDC Controller (Enabled)
Select Enabled if your system has a floppy disk controller (FDC) installed on the system
board and you wish to use it. If you install an add-in FDC or the system has no floppy drive,
select Disabled in this field.
Onboard Serial Port1 (3F8/IRQ4)
This option is used to assign the I/O address and interrupt request (IRQ) for onboard serial
port1/2 (COM1/2).
Onboard Parallel Port (378/IRQ7)
This option is used to assign the I/O address and interrupt request (IRQ) for the onboard
parallel port.
ECP Mode Use DMA (3)
When the onboard parallel port is set tp ECP mode, the parallel port can use DMA3 or
DMA1.
Parallel Port Mode (ECP)
Enables you to set the data transfer protocol for your parallel port. There are four options:
SPP (Standard Parallel Port), EPP (Enhanced Parallel Port), ECP (Extended Capabilities
Port), and ECP+EPP.
SPP allows data output only. Extended Capabilities Port (ECP) and Enhanced Parallel Port
(EPP) are bi-directional modes, allowing both data input and output. ECP and EPP modes
are only supported with EPP- and ECP-aware peripherals.
