ECS NF650iSLIT-A - Page 46

40
Using BIOS
RAID Enable (Disabled)
This item allows you to enable or disable the onboard RAID function of RAID
supporting devices.
SATA 1/2 Primary/Secondary RAID (Disabled)
These two items enable or disable the SATA1/2 Primary and Secondary RAID.
RAID Config (Press Enter)
Scroll to this item and press <Enter> to view the following screen:
X
Phoenix-AwardBIOS CMOS Setup Utility
RAID Config
Press <Esc> to return to the Integrated Peripherals page.
Onboard Device (Press Enter)
Scroll to this item and press <Enter> to view the following screen:
X
Phoenix-Award WorkstationBIOS CMOS Setup Utility
Onboard Device
Item Help
ff
Menu Level
OnChip USB [V1.1 + V2.0]
USB Legacy Support [Enabled]
USB Mouse Support [Enabled]
USB Storage Support [Enabled]
HD Audio [Auto]
Onboard LAN [Auto]
Onboard Lan Boot ROM [Disabled]
F5:Previous Values F6: Fail-Safe Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
RAID Enable
SATA 1 Primary RAID [Disabled]
SATA 1 Secondary RAID [Disabled]
SATA 2 Primary RAID [Disabled]
SATA 2 Secondary RAID [Disabled]
Item Help
ff
Menu Level
[Disabled]
x
x
x
x
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
OnChip USB (V1.1+V2.0)
This item enables users to enable or disable the onchip USB function, setting it to be
USB1.1 or USB2.0 compatible.
