DIGITAL ECU TUNER 3 – User Manual
Sygnał SAW modułu EDIS
In case of the ignition controlling the EDIS module, it is possible to modify the ignition angle through the length
modification of the controlling SAW signal.
For this type of signal, in the menu Setup/Ignition Configuration choose Ignition Input Type: Hall Effect or
optical sensor.
Page 24
www.ecumaster.com
1 PIP
2 IDM
3 SAW
4 IGN GND
5 VRS-
6 VRS+
7 VRS Shield
8 VPWR
9 PWR GND
10 COIL 1
11 CTO
12 COIL 2
EDIS 4 CYL
Ignition Out (6)
Ignition In (9)
DET 3
ECU
