Mechanical Drawings
09
A
Welcome to choose
EcubMaker
TOYDIY frontside view
TOYDIY Backside view
--------
Filament tube
Toolhead Cable
Toolhead
Print plate
X-Axis
Y-Axis
Z-Axis
X-Axis motor
Handle
Power switch
Menu Button
USB cable Slot
SDcard Slot
Display
① extruder
② extruder
Pla filament
Filament tube
Y-Axis motor
Power adapter jack
X-Axis limit switch
Y-Axis limit switch
Extruder block
Extruder blockExtruder block
Extruder block
