iSE Series Electrocardiograph User Manual Introduction
1 2
Name Description
1 Paper tray (option) Contains thermal chart paper roll.
2 Handle (option) /
Figure 5 Right
1 2 3 4
Name Description
1 ECG cable socket Connects to the ECG cable.
2 DE18 socket Connects to the DE18 connection cable.
3 Fingerprint identifier
Identifies user fingerprint for login to the
electrocardiograph.
To power on, press and hold the On/Off button
when the device is off.
4 On/Off button
When the device is on:
- 5 -
