– 25 –
1 INTRODUCTION
OVERVIEW
The ECS2000-10P is a Gigabit Ethernet Layer 2 PoE switch with 8 10/100/
1000BASE-T ports, and 2 Small Form Factor Pluggable (SFP) transceiver slots,
(see "Front Panel" on page 25, Ports 9-10). The ECS2000-10P also provides PoE
power to connected devices.
The switch also includes an SNMP-based management agent, which provides in-
band access for managing the switch.
Both switches provide a broad range of powerful features for Layer 2 switching,
delivering reliability and consistent performance for your network traffic. It
brings order to poorly performing networks by segregating them into separate
broadcast domains with IEEE 802.1Q compliant VLANs, and empowers
multimedia applications with multicast switching and CoS services.
Figure 1: Front Panel
System Indicators
1000BASE-T/SFP Ports
10/100/1000 Mbps RJ-45 PoE Ports
Port Status Indicators
Reset Button
SFP Port Status Indicators

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Edge-Core ECS2000-10P and is the answer not in the manual?

Edge-Core ECS2000-10P Specifications

General IconGeneral
ModelECS2000-10P
TypeManaged Switch
Ports10
PoE Ports8
PoE Budget130W
Switching Capacity20 Gbps
Forwarding Rate14.88 Mpps
LayerLayer 2
MAC Address Table Size8K
Weight3.5 kg
Power over EthernetIEEE 802.3af/at
Power SupplyAC 100-240V, 50/60Hz
Operating Temperature0 to 50 °C
Storage Temperature-40 to 70 °C
Humidity10% to 90% (non-condensing)
