C HAPTER 1 | Introduction
Description of Hardware
– 31 –
RESET BUTTON
If you encounter any switch malfunctions, such as a hang or non-recoverable
error, you might want to reset the switch to its default configuration by pressing
and holding the reset button for more than 10 seconds. The reset button is
located on the front panel.
Figure 6: Reset Button
Reset Button

Edge-Core ECS2000-10P Specifications

General

Model	ECS2000-10P
Type	Managed Switch
Ports	10
PoE Ports	8
PoE Budget	130W
Switching Capacity	20 Gbps
Forwarding Rate	14.88 Mpps
Layer	Layer 2
MAC Address Table Size	8K
Weight	3.5 kg
Power over Ethernet	IEEE 802.3af/at
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0 to 50 °C
Storage Temperature	-40 to 70 °C
Humidity	10% to 90% (non-condensing)
