Specifications
C-2
C
AC Input
100 to 240 V, 50-60 Hz, 1.5 A
Power-over-Ethernet
Input voltage: 48 V DC
Maximum output power 70 W:
15.4 W for any four ports simultaneously
port 1 can provide 25 W
Maximum output current per port: 350 mA DC
port 1 can reach: 565 mA DC
Output Voltage: 44 - 57 V DC
Maximum output current per port: 350 mA DC
Power Supply
Internal, auto-ranging transformer: 100 to 240 VAC, 50 to 60 Hz
Power Consumption
165 W maximum (full PoE load)
Maximum Current
1.5 A @ 110 VAC
0.75 A @ 220 VAC
Switch Features
Forwarding Mode
Store-and-forward
Throughput
Wire speed
Management Features
In-Band Management
Web and SNMP
Software Loading
HTTP in-band
