EDGE30 / EDGE2440 / EDGE40 / EDGE2460 / EDGE60 / EDGE3860
Installation and Operating Manual
Original Instruction Manual 27 Rev 2.1 July 12, 2016
SPECIFICATIONS EDGE3860
Minimum Clearances:
Oven Back to Wall ............................................................. 6.0”
Control Side Conveyor to Wall ......................................... 6.0”
Non-Control Side Conveyor to Wall ................................. 6.0”
Dimensions:
Overall Height – Single-Stack ........................................... 44.00”
Belt ................................................................................. 31.75”
Overall Height – Double-Stack .......................................... 64.50”
Belt, top oven ................................................................ 52.00”
Overall Height – Triple-Stack ............................................ 69.00”
Belt, top oven ................................................................ 56.75”
Length ................................................................................. 93.75”
Depth ................................................................................... 63.00”
Belt Width ........................................................................... 39.75”
Electrical Specifications:
Operating Voltage .............................................................. 120 VAC
Phase .................................................................................. Single
Frequency ........................................................................... 60 Hz
Current Draw ...................................................................... 5.5 Amps
Shipping Weight
Single Oven ........................................................................ 1270 LBS.
*estimate weights only
