EDGE30 / EDGE2440 / EDGE40 / EDGE2460 / EDGE60 / EDGE3860
Installation and Operating Manual
Original Instruction Manual 35 Rev 2.1 July 12, 2016
RESTRAINT CABLE
IMPORTANT
OVENS EQUIPPED WITH CASTERS:
(1) The installation shall be made using a connector that complies with the
standard Connectors for Movable Gas Appliances, ANSI Z21.69 (CSA 6.16)
and a quick-disconnect that complies with the standard Quick-Disconnect
Devices for use with Gas Fuel, ANSI Z21.41 (CSA 6.9).
(2) Adequate means must be provided to limit movement of the appliance
without depending on the connector, quick-disconnect device, or associated
piping to limit appliance movement.
(3) The restraining device must be attached to the mounting eye located on the
left side of the oven base assembly.
All EDGE ovens are equipped with casters, and a restraint cable must be installed to
limit movement of the oven without straining the gas or electrical connections. One end
of the restraint cable is anchored to the wall, and the other end is anchored to the
mounting eye located on the left side of the oven base assembly.
Ensure that the restraint cable limits movement of the oven so that no strain is placed on
either the gas supply quick-disconnect fitting or the electrical power cord.
After connecting the restraint cable, move the oven into its final position and lock the
casters.
Whenever any maintenance or service is performed and the restraint must be
disconnected, ensure that it is reconnected as soon as the oven is returned to its normal
installed position.
WARNING
Use only the cord set supplied by the oven OEM, or a direct replacement cord set
purchased from the oven OEM. Other cord sets may present a fire and/or electric
shock hazard.
