EDGE30 / EDGE2440 / EDGE40 / EDGE2460 / EDGE60 / EDGE3860
Installation and Operating Manual
Original Instruction Manual 3 Rev 2.1 July 12, 2016
OVEN CONTROLS
Digital Speed Control: Sets the product baking time (conveyor speed) of the oven
between 3:00 to 30:00 minutes (MM:SS format). Pressing the up arrow (▲) key
increases the baking time, and pressing the down arrow (▼) decreases the baking time.
Figure 1: Digital Speed Control
Digital Temperature Control: Sets the oven temperature from 350˚ to 600 °F as
desired for the product being baked. Pressing the up arrow (▲) key increases the
baking temperature, and pressing the down arrow (▼) decreases the baking
temperature. The upper display shows the actual oven temperature, and the lower
display shows the oven temperature setting. ( ) allows selection and adjustment of a
second temperature set point. ( ) will momentarily display the valve ouptut in %, and
the set point 1 & 2 values.
Figure 2: Digital Temperature Control
NOTE
Both the speed and temperature controls are preset at the factory. Contact an
authorized service agent or MF&B Restaurant Systems, Inc., for further information on
these controls and their factory settings.
