Edge Juice - EGT Sensor Mounting

22
Figure 5
Figure 6
The EGT
thermocouple
installed into the
drilled and
tapped exhaust
manifold
Tip: Pulling
back the wheel
splash guard
provides easy
access to the
exhaust manifold
for tapping the
EGT cable.
