27
Changing Variables on the Screen
The following is a list of main options that can be performed on the Attitude,
the majority of which have sub-options for advanced settings:
• Boost
• EGT (exhaust gas
temperature)
• Barometric PSI*
• Speed MPH
• Engine Coolant Temp*
• Gear (TCC Lock)
• Intake Air Temp*
• Load %
• Slip %
• Transmission Temp*
• Throttle %
• Turbo Boost PSI
• RPM
• Percent back down due to
high EGT
*’01 Duramax does not display Barometric PSI, Intake Air Temp, Engine Coolant
Temp, and Transmission Temp.
*’02 Duramax does not display Transmission Temp.
Display
To change the variables on the screen, perform the following steps:
1. When viewing the main screen of variables, press the [Menu] button.
The following screen appears:
