Chevy/GM Juice Getting Connected
Supplied Items:
1. Power Edge Juice Module
2. Three Wire Ties
3. Two Velcro Strips
Required Tools:
None
Please read these instructions completely so that you understand each step
prior to installation
.
The Power Edge Juice Module
This picture shows the Power Edge Juice Module with the harness cable and
Edge Attitude Display wiring (Attitude instructions on pg. 13)
Connected
These two
connectors are
EGT
thermocouple
connections.
This cable is
where the
optional Edge
Attitude Display
module gets
connected.
