6 Operations Manual
Note:
If there are no active points within the Alarm, Supv Short,
Trouble, Alert, Output, Disabled Zones, Disabled Messages, Disabled
Actions, Disabled Sequences, or Test Mode categories, then nothing
will appear on the screen for that category.
Press the Next/Ack button to scroll the display. The display shows
the following:
Alarm Status. Use Next to scroll
0114
In this example, 0114 indicates panel address 01, zone 14. A maximum
of eight (8) addresses and zones can be displayed simultaneously. Press
the Next/Ack button to reveal additional zones.
Press the Next/Ack button to scroll the display. The display shows
the following:
Trouble Status. Use Next to scroll
0401
In this example, 0401 indicates panel address 04, zone 01.
Press the Next/Ack button to scroll the display. The display shows
the following:
Supv Short Status. Use Next to scroll
0401
In this example, 0401 indicates panel address 04, zone 01.
Press the Next/Ack button to scroll the display. The display shows
the following:
Field Panel Status. Use Next to scroll
Pnl# XX ComP ok ComS oK ComE ds
Press the Next/Ack button to scroll the display. The display shows
the following:
Alert Status. Use Next to scroll
Press the Next/Ack button to scroll the display. The display shows
the following:
Output Status. Use Next to scroll
Press the Next/Ack button to scroll the display. The display shows
the following:
Disabled Zones. Use Next to scroll
Press the Next/Ack button to scroll the display. The display shows
the following:
