S149-01-880 Issue F
Page 10 © Edwards Limited 2011. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
Figure 7 - 412-J pump dimensions
Table 4 - Motor specifications, NEMA motors
Specification 900-149-011 930-149-011 900-212-014 900-412-014
Enclosure TEFC TEFC TEFC TEFC
Ambient temperature 40 °C (104 °F) 40 °C (104 °F) 40 °C (104 °F) 40 °C (104 °F)
Frame 182T 184T 213T 215T
Insulation class F4 F4 F F
Electrical supply 230/460 230/460 230/460 230/460
Service factor 1.15 1.15 1.15 1.15
Duty Continuous Continuous Continuous Continuous
Mounting F1F1F1F1
