STP-301/451 Series Instruction Manual

8-11
Operation

Table 8.8 shows rated contacts for relays CR4, 5, 6, 7, 8, 9 and 10. (see Figure 8.4)

Table 8.8    Rated Contacts for Relays CR4, 5, 6, 7, 8, 9 and 10


Resistance Load
(cos  φ=1)
Induction Load
(cos  φ=0.4)
(L/R=7 ms)
125 VAC 0.4 A  125 VAC 0.2 A
Rated Load
30 VDC  2 A  30 VDC  1 A
Rated Current  3 A
Maximum Contact
Point Voltage
250 VAC
220 VDC
Maximum Contact
Point Current
3 A
Maximum Open/Close
Capacity
AC: 50 VA
DC:  60 W
AC: 25 VA
DC:  30 W
Minimum
Applicable Load
DC10m V 10  μA


8.3.3  Remote Cables (Optional Accessories)
Remote cables for CON4 are provided as optional accessories.
Remote cables are available in two types: single-side connector type and both-side connector
type. Contact Edwards for details.

Table 8.9 shows connections of remote cables of single-side connector type.

Table 8.9    Remote Cable Connections (Single-Side Connector Type)

Connector
Pin No.
Cable Color
Connector
Pin No.
Cable Color
1
Brown 13 White/Orange
2
Red 14 White/Yellow
3
Orange 15 White/Green
4
Yellow 16 White/Blue
5
Blue 17 Green
6
Purple 18 White/Black/Brown
7
Gray 19 White/Black/Red
8
White 20 White/Black/Orange
9
White/Black 21 White/Black/Yellow
10 White/Brown 22 White/Black/Green
11 White/Red 23 White/Black/Blue
12, hood  Shielded  24  White/Purple, White/Gray
