Technical data
A726-01-880 Issue M
2Technical data
2.1 Operating and storage conditions
2.2 Performance
2.2.1 General
General characteristics of the pumps are defined in Table 1 below. Characteristics shown are displacement, pumping
speed and maximum permitted interface pressures.
Suckback on pump switch off typically 30 mbar ls
-1
(leak tightness 1x10
-6
mbar ls
-1
).
Table 1 - General characteristics
* The XDS pumps can survive an excursion to 1 bar gauge in the exhaust line. However, under normal
operating conditions (with the pump running) the exhaust line pressure should be as close as possible to
atmospheric pressure. If the pump is operated with a raised exhaust line pressure this will accelerate tip
seal wear and lead to a loss of pumping performance.
Ambient temperature:
Operating range 10 °C to 40 °C
Storage range -30 °C to 70 °C
Surface temperature of pump above ambient (when operating at ultimate) typically 45 °C
Maximum humidity (operation) 90%
Altitude up to 2000 m
XDS 10 XDS 5
Maximum displacement (m
3
/hr)
50 Hz electrical supply
60 Hz electrical supply
11.3
13.4
5.7
6.7
Maximum pumping speed (m
3
/hr)
Pneurop 6602 (1979)
50 Hz electrical supply
60 Hz electrical supply
9.3
11.1
4.8
6.0
Maximum permitted inlet pressure and
gas-ballast inlet pressure
Maximum permitted outlet pressure *
0.5 bar gauge
1 bar gauge
0.5 bar gauge
1 bar gauge
