Edwards XDS46i

3. Technical data
WARNING:
If the pump is operated outside the specic limits, the pump housing may become
hot.
3.1 Operang and storage condions
Table 1
Operang and storage condions
Ambient temperature range (operaon) + 10 °C to + 40 °C
Maximum surface temperature of pump body
under normal operang condions and
maximum ambient temperature
+ 40 °C to + 65 °C
Maximum humidity (operaon) 90% RH
Ambient temperature range (storage) - 30 °C to + 70 °C
Polluon Polluon degree 2
Installaon Installaon category II
Altude restricon Maximum 2000 m
Area of use Indoor use
3.2 Performance
Table 2
General characteriscs
Maximum pumping speed
40 m
3
/h
Maximum
permied connuous inlet pressure
40 mbar
Maximum permied connuous exhaust
pressure
1.2 bar (a)
Maximum permied gas ballast inlet pressure 1.5 bar (a)
Maximum chamber volume to pump down from
atmospheric pressure
100 litres
Maximum chamber volume for cyclic
duty‑maximum 6 cycles per hour
50 litres
Maximum inial pressure rise with no gas
ballast ow
5 mbar l
Suck‑back protecon By exhaust valve
Leak ghtness
< 1 x 10
-6
mbar l s
-1
Maximum displacement
60 m
3
/hr
Page 11
A73101880_F - Technical data
