4.5 Electrical installaon
4.5.1 Check and congure the pump
CAUTION:
Isolate the power supply before changing the voltage. Failure to congure the pump
electrical supply correctly can result in damage to the pump.
Ensure that the voltage shown on the voltage indicator (refer to Figure: General view on
page 9) on the motor cover corresponds with the electrical supply voltage. If not, change
the conguraon of the pump motor to match the supply voltage using the following
procedure.
1.
Undo the two screws and li o the voltage indicator moulding.
2.
Rotate the voltage indicator moulding so that the correct voltage is uppermost.
3.
Replace the two screws.
4.5.2 Connect the pump to the electrical supply
WARNING:
Ensure that the XDS pump electrical installaon conforms to local and naonal safety
requirements. It must be connected to a suitably fused and protected electrical
supply with a suitable earth (ground) point.
WARNING:
If using an earth leakage device, for example, an RCD, use a 30 mA rated unit at
minimum to avoid tripping during start up.
WARNING:
The pump will automacally restart aer restoraon of the power supply following
power failure.
For recommended regional supply protecon and cordsets, refer to Electrical data on
page 13.
4.6 Inlet and outlet connecons
WARNING:
If pumping dangerous gases or vapours, connect the exhaust to a suitable treatment
plant to prevent the discharge of dangerous gases and vapours to the surrounding
atmosphere.
Page 19
A73101880_F - Installaon
