7. Delay Judgment Time Setting
As the Frequency display indicates “dLAy” and the Voltage display indicates “t”, press the “︿” or
“﹀” key from the Current display to adjust the delay time between “0” ~ “9999”. The delay
judgment time is set to assign time period that will not make any judgment to all limits (Ex: A,P,PF
High／Low Limit Setting).
Note: The delay judgment time may not longer than the testing time. If the testing time has been
selected to “Cont”, the delay judgment time will be fixed to “0”, and therefore, the run operation
is always carried out with the limit judgments.
8. Current High Limit Setting
As the Voltage display indicates “A-HI”, press the “︿” or “﹀” key from the Current display to
select “OFF” or “0.0”~“Maximum capacity current (Ex: 10KVA, 84A/42A)”. Setting of “OFF” means
no judgment to be made. Note: Whenever there is a pressing on the “︿” or “﹀” key from the
Current display during the RESET condition, it will also change the current high limit setting value.
9. Current Low Limit Setting
As the Voltage display indicates “A-LO”, press the “︿” or “﹀” key from the Current display to
select “OFF” or “0.1”~“Maximum capacity current (Ex: 10KVA, 84A/42A)”. Setting of “OFF” means
no judgment to be made.
10. Power High Limit Setting
As the Voltage display indicates “P-HI”, press the “︿” or “﹀” key from the Current display to
select “OFF” or “0.01”~“Maximum capacity power (Ex: 10KVA, 10.00KW)”. Setting of “OFF” means
no judgment to be made.
11. Power Low Limit Setting
As the Voltage display indicates “P-LO”, press the “︿” or “﹀” key from the Current display to
select “OFF” or “0.01”~“Maximum capacity power (Ex: 10KVA, 10.00KW)”. Setting of “OFF” means
no judgment to be made.
12. Ramp Up Setting
As the Frequency display indicates “rAnP” and the Voltage display indicates “UP”, press the “︿”
or “﹀” key from the Current display to select “OFF” or “0.1”~“999.9”.
13. Ramp Down Setting
As the Frequency display indicates “rAnP” and the Voltage display indicates “dOun”, press the
“︿” or “﹀” key from the Current display to select “OFF” or “0.1”~“999.9”.
