2. Auto Loop Cycle Setting
The Frequency display will indicate “LooP” and the Voltage display shows “CyCL”. Press the “︿”
or “﹀” key from the Current display to select “Cont”, “OFF” and “2”~”999”. Setting of “Cont”
means continuous, and “OFF” is single operation. For “2”~“9” setting, it becomes the number of
sequence to be repeated for running operation. This selected loop cycle will then be multiplied by
the “LooP CyCL” of the SYSTEM parameter, which acts as a multiplier (×1, ×10 or ×100) to the
selected value of ”LooP CyCL”. (For example, Loop Cycle is set to “2” and the Loop Rate has
selected “×10”. Therefore, the Auto run operation will execute for 20 times.)
3. Program Memory Step Selection
As the Voltage display indicates “StEP”, press the “︿” or “﹀” key from the Current display to
select “1”~ “5”. Each Program memory is consisting of 5 Steps that different settings on voltage,
frequency, testing time, current, power, and power factor high/low limits can be stored at each
step individually.
4. Output Voltage Setting
As the Voltage display indicates “Volt”, press the “︿” or “﹀” key from the Current display to
adjust voltage within the range of “0.0”~“Maximum Voltage”. For the voltage set above low
voltage range, the high voltage range must be selected. Any alteration to be made for the voltage
setting on the Voltage display during the RESET condition will also change the other voltage
setting value for auto run operation as well.
5. Output Frequency Setting
As the Voltage display indicates “FrEq”, press the “︿” or “﹀” key from the Current display to
adjust the frequency within the range of “47.0”~“63.0”.. Any alteration to be made for the
frequency setting on the Frequency display during the RESET condition will also change the other
frequency setting value for auto run operation as well. Note: Else two ranges: 45.0-500.0Hz and
400Hz for option.
6. Testing Time Setting
As the Frequency display indicates “tESt” and the Voltage display indicates “t”, press the “︿” or
“﹀” key from the Current display to select “Cont” or “1” ~ “9999”. Setting of “Cont” means
continuous, which repeats after the time has reached “9999”. The testing time will be executed
that is based on the testing time unit (SEC, Min, or Hour) being set under the SYSTEM parameter.
Press “RESET” key on the front panel in order to terminate the testing operation. The testing time
setting is defined as the setting of time that is required for the Loop Cycle to execute a single
operation.
