U S E R M A N U A L E P S - D
Technical specifications and data are subject to change without any prior notice.
17
Example B-3
Testplug:
JP1 pin 1 connected to JP1 pin 4
JP2 pin 1 connected to JP1 pin 5
This can be used to activate all of the outputs for maintenance purposes.
The outputs will be activated as long as the connections are present and the
display will show that an external input is active.
The outputs are supplied be mains and the batteries continue being charged.
