USV MT3200 Instruction manual
MT Series
Page 12 of 36
6 Description of equipment –MT3200
In this chapter, you will be introduced to the various elements of the equipment
and will be provided with instructions on its operation as well as all information
on equipment connections.
6.1 Display and operator control elements on the front panel
Fig. 2:
Front view
MT3200
All of the operator control and display elements required for normal operation
are positioned on the front of the equipment.
6.1.1 Operator control elements of the UPS
Fig. 3:
Display and
operator control
panel
MT3200
