USV MT3200 Instruction manual
MT Series
Page 2 of 36
Contents
1 Presentation 4
2 Warranty conditions 5
2.1 Limitation of liability 6
3 Safety 7
3.1 General safety instructions 7
3.2 Transportation and storage 7
3.3 Setup 7
3.4 Connection 8
3.5 Operation 8
3.6 Handling batteries 9
3.7 Maintenance, servicing and faults 9
4 Introduction 10
5 System description 11
6 Description of equipment –MT3200 12
6.1 Display and operator control elements on the front panel 12
6.1.1 Operator control elements of the UPS 12
6.1.2 Display elements of the UPS 13
6.2 Equipment elements on the rear panel 14
6.3 Audible alarm signals of the UPS 16
7 Storage and unpacking 17
7.1 Storing the UPS 17
7.2 Unpacking the equipment 17
8 Installing and connecting the UPS 18
8.1 Connecting the UPS 19
8.2 Communications connection of UPS 20
8.3 Connection sequence 20
9 Operating and controlling the equipment 21
9.1 Operating the UPS equipment 21
9.1.1 Operating modes and signals 21
9.2 Instructions for using the UPS 25
9.2.1 Switching on the UPS 25
9.2.2 Switching off the UPS 25
9.2.3 Activating test mode 25
9.2.4 Communication 26
10 Starting up the UPS equipment 27
11 Troubleshooting 27
12 Software 29
13 Maintenance and servicing 30
