Hardware Overview
Document ID: OMM-00174 Rev. D Pro 30f Operations Guide 17
3.1.1.3 EFI Pro 30f UV Lamps
The EFI Pro 30f is equipped with UV Lamps which provide a superior technology for ink curing.
C
A
D
E
F
B
Figure 3-4 : LED Lamp Detail (Right Lamp Shown)
A Lamp Interface Board Housing D Fans & Filter Assemblies
B Lamp Mounting Bracket Assembly E Electrical/Communications Connection Point
C Anti-static Bar Assembly F Carriage Safety Stop Assembly
