Hardware Overview
Document ID: OMM-00174 Rev. D Pro 30f Operations Guide 21
This section illustrates the systems and compartments accessible from the rear of the printer.
3.2 Rear Access
Caution: Keep all safety interlocks, covers, and guards in place and functional. Never operate
printer with covers, doors, or guards removed or with malfunctioning interlocks.
Figure 3-10 : Printer Rear Access
A Electrical Connector
B Ink Supply and Pump Compartment
C Cyclonic Vacuum System
D Energy Chain
C
A
B
D
