Hardware Overview
Document ID: OMM-00174 Rev. D Pro 30f Operations Guide 20
3.1.4 Operator Station Components
The Pro 30f computer components are attached to the front right of
the printer. The components are:
• A 22” flat-panel display
• A full-size keyboard,
• A two-button wheel-mouse.
C
A
B
Figure 3-9 : Operator Station
A Monitor
BKeyboard
CMouse
