EFI Pro 30f - Tool Bar

Software Overview
Document ID: OMM-00174 Rev. D Pro 30f Operations Guide 28
4.1 Tool Bar
CA D E
F
B G H I
Figure 4-2 Tool Bar
A Print a nozzle test. D Move the carriage to the left/right or
up/down.
GEngage vacuum.
B Click button for auto media thickness
detection.
E Print job selected in the queue. H Toggle printer from sleep status
to wake status and back.
C Purge and sweep all print heads. F Move gantry to front/back of printer. I Open the Test Printer settings
window.
