3.2.4 Energy Chain

The Energy Chain (E-Chain) is attached to the back side of the carriage and moves with the carriage when it is in motion

during printing operations. The E-Chain continuously supplies the moving carriage with the following:

•White Ink

•CMYK Ink

• Electrical Power

• Positive and Negative Pressure

• Communication Signals

• Printing Data

Figure 3-15 : Energy Chain (E-Chain)

AE-Chain

B Internal Tubes and Wiring

CE-Chain Trough Cover

DE-Chain Trough
