Software Overview
Document ID: OMM-00174 Rev. D Pro 30f Operations Guide 30
4.2.1 PLC GUI (Controls/Ink) Window
The PLC GUI (Controls/Ink) window enables the operator to set
up sub–tank temperature, light density, and negative pressure. It
also indicates ink level status.
There are two ways to open PLC (Controls/Ink) window. The first
is to choose Setting on the main interface to open the Test
Printer window and then select the PLC button. Second, the
window can be directly opened from the folder containing the
whole Pro 30f driver location.
Figure 4-4 PLC Button on Test Printer window
