EFKA DA82GA3312
18
↓
↓↓
↓
Righthand arrow above key 1 blinks.
8
Number of stitches for the start backtack 
section forward is displayed. Vary the
number of stitches using the +/- key.
If a different key is pressed, start backtack section input is completed, and the righthand arrow above key 1 stops blinking.
The double start backtack is enabled.
↓
↓↓
↓
Righthand arrow above key 6 On.
9
Sewing foot lift at the seam end is On. 
↓
↓↓
↓
Lefthand arrow above key 2 On.
10
Stitch counting forward is On. 
Change the number of stitches using the +/- keys,
11
or execute the seam section using the pedal. 
Seam length is set at 17 stitches !
12
Pattern 4, seam 2 
↓
↓↓
↓
Lefthand arrow above key 2 On.
13
Stitch counting forward is On. 
Change the number of stitches using the +/- keys,
14
or execute the seam section using the pedal. 
 Seam length is set at 8 stitches !
15
 Pattern 4, seam 3. 
Free seam is selected.
↓
↓↓
↓
Lefthand arrow above key 3 On.
16
 Light barrier covered/uncovered is On. 
Change the number of stitches using the +/- keys;
17
5 compensating stitches are set. 
↓
↓↓
↓
Lefthand arrow above key 4 blinks.
18
Number of stitches for the end backtack 
section backward is displayed. Vary the
number of stitches using the +/- key.
If a different key is pressed, end backtack section input is completed, and the lefthand arrow above key 4 stops blinking.
The single end backtack is enabled.
↓
↓↓
↓ ↓
↓↓
↓
Both arrows above key 5 On.
19
Thread trimmer and thread wiper are On. 
Pattern 4, seam 4.
20
Advance to the next seam acknowledges 
the settings of the preceding seams.
Exit programming;
21
the first seam can be executed ! 
2 4 01 000
+
- 4 01 017
E
4 02 - - -
2 4 02 000
+
- 4 02 008
1 4 01 - - - 04
3 4 03 - - - 000
+
- 4 03 - - - 005
E
4 04 - - -
E
4 03 - - -
P
4 01 017
4
5 4 03 - - - 005
6 4 01 - - -
4 01 - - - 04
