Eizo ColorEdge CG276 - Table of Contents; Contents

5
CONTENTS
CONTENTS
Cover ...................................................................... 1
Notice for this monitor ......................................... 3
Cleaning .................................................................... 4
To use the monitor comfortably ............................. 4
CONTENTS ............................................................. 5
Chapter 1 Introduction ....................................... 7
1-1. Features ......................................................... 7
1-2. Controls and Functions ............................... 9
1-3. EIZO LCD Utility Disk...................................10
●
Diskcontentsandsoftwareoverview............10
●
TouseColorNavigator...................................10
1-4. Basic Operations and Functions ...............11
●
BasicAdjustmentmenuoperations...............11
●
ShowingButtonGuide...................................12
●
Functions........................................................13
Chapter 2 Adjusting Screens .......................... 15
2-1. Compatible Resolutions .............................15
●
DigitalInput(DVI-D,DisplayPort)..................15
●
DigitalInput(HDMI)........................................15
2-2. Setting Resolution .......................................16
●
Windows8/Windows7.................................16
●
WindowsVista................................................16
●
WindowsXP...................................................16
●
MacOSX.......................................................16
2-3. Adjusting Color ............................................17
●
Toselectthedisplaymode(colormode).......17
●
Toperformadvancedadjustments................18
●
Adjustablesettingsineachmode..................18
●
AdjustingBrightness......................................19
●
Adjustingthetemperature..............................19
●
AdjustingGamma.......................................... 20
●
AdjustingHue................................................ 20
●
AdjustingSaturation.......................................21
●
Toenhanceoutlineofimage..........................21
●
Tosetclipping............................................... 22
●
AdjustingGain............................................... 23
●
Adjustingthebrightnessandcolorof
black“BlackLevel”........................................ 23
●
Adjusting6Colors..........................................24
2-4. Expanding Signal Output Range .............. 24
2-5. Selecting Screen Size ................................ 25
●
DVI,DisplayPort(PCsignal)input................ 25
●
HDMI(HDsignal)input................................. 26
●
HDMI(SDsignal)input................................. 26
2-6.
Conguring Moving Image Performance .... 27
2-7. Specifying Color Space ............................. 27
2-8. Setting HDMI ................................................ 28
●
Reducingnoise............................................. 28
●
Selectinghowtodisplayinterlacesignal...... 28
●
SettingSafeArea.......................................... 29
Chapter 3 Setting Monitor ............................... 31
3-1. Enabling/Disabling Mode Selection ..........31
3-2. Selecting the Language ..............................31
3-3. Setting Orientation ......................................31
3-4. Changing Adjustment Menu Display
Position ........................................................ 32
3-5. Showing and Hiding the EIZO Logo ......... 32
3-6. Locking Operation Buttons ....................... 32
3-7. Setting Signal Bandwidth .......................... 33
3-8. Switching USB Port Automatically ........... 33
3-9. Changing DUE (Digital Uniformity
Equalizer) Setting ....................................... 34
3-10. Reset to default ........................................... 34
●
Toresetthecoloradjustments...................... 34
●
Toresetalladjustmentstothedefault
settings.......................................................... 35
Chapter 4 SelfCalibration ................................ 36
4-1. Setting Calibration Details ......................... 36
●
Settingmonitordateandtime....................... 36
●
Settingcalibrationschedule...........................37
●
SetthemodeforwhichSelfCalibration
isexecuted.................................................... 38
●
SettingAdjustmentTarget............................. 39
4-2. Executing SelfCalibration .......................... 39
4-3. Checking Adjustment Results ................... 40
Chapter 5 Power Saving Functions ................ 41
5-1. Setting Power Save ......................................41
5-2. Sets the brightness of the indicator ......... 42
5-3. Setting DisplayPort Power Save ............... 42
Chapter 6 Troubleshooting .............................. 43
6-1. No picture .................................................... 43
6-2. Imaging problems ....................................... 44
6-3. Other problems ........................................... 45
6-4. Built-in calibration sensor and
SelfCalibration problems ........................... 46
Chapter 7 Reference ........................................ 47
7-1. Attaching the Optional Arm ........................47
7-2. Connecting Multiple External Devices ..... 48
●
Toswitchamonginputsignals...................... 49
●
Tosetinputsignalselection“Input
Selection”...................................................... 49
