Eizo ColorEdge CS2420 User Manual

- 11 -
Chapter 1
Introduction
1-3. EIZO LCD Utility Disk
An “EIZO LCD Utility Disk” (CD-ROM) is supplied with this product. The following table shows the disk contents and an overview of the software programs.
●
Disk contents and software overview
The disk includes application software programs for calibration, and the User's Manual. Refer to “Readme.txt” or the “read me” le on the disk for software
startup procedures or le reference procedures.
Contents Overview
A “Readme.txt” or “read me” le
ColorNavigator 6 An application software for measuring and calibrating monitor characteristics and generating ICC proles (for Windows) and
Apple ColorSync proles (for Macintosh).
(The monitor and PC must be connected using the USB cable.)
User’s Manual of this monitor (PDF le)
●
To use ColorNavigator 6
Refer to the User’s Manual on the CD-ROM disk in order to install and use the software. When using this software, you will need to connect a PC to the
monitor with the supplied USB cable. For details of the USB cable connection, see page 43.
Attention
• While using ColorNavigator 6, do not operate the power switch or operation switches on the front side on the monitor.

Eizo ColorEdge CS2420 Specifications

General

Screen Size	24.1 inches
Resolution	1920 x 1200
Panel Type	IPS
Aspect Ratio	16:10
Brightness	300 cd/m²
Contrast Ratio	1000:1
Response Time	15 ms (Gray-to-Gray)
Connectivity	DisplayPort, HDMI, DVI-D
Color Gamut Coverage	99% Adobe RGB
Calibration	Hardware Calibration
Stand Adjustments	Height, Tilt, Swivel, Pivot
Color Support	1.07 billion colors
Viewing Angles	178° horizontal / 178° vertical
USB Ports	2 x USB 3.0 downstream, 1 x USB 3.0 upstream
