- 7 -
Chapter 1
Introduction
Chapter 1 Introduction
Thank you very much for choosing an EIZO color LCD monitor.
1-1. Features
• 24.0″ widescreen
• Wide color gamut display (Adobe
®
RGB coverage: 99%)
• Supports a resolution of 1920 × 1200
• IPS panel with 89˚ horizontal and vertical wide viewing angles
• Frame synchronization mode supported (23.75 – 30.5 Hz, 47.5 – 61.0 Hz)
• Support for three digital signal inputs (DVI-D × 1, HDMI × 1, DisplayPort × 1)
- DisplayPort connector (applicable to 8 bit and 10 bit)
*1
- HDMI connector (applicable to 8 bit, 10 bit, and 12 bit)
*1,*2
Can handle PC signals in HDMI input
*1 Not applicable to audio signals.
*2 10 bit and 12 bit are supported only when using HDMI-Video. The maximum screen display is 10 bits.
• Color mode function
Reproduces a color temperature, gamma, and gamut compliant with the following standards.
- Adobe
®
RGB / sRGB
See “Chapter 3 Advanced Adjustments/Settings” (page 18)
• Stand with wide range of movement
The monitor can be adjusted to a position where it provides you with a comfortable and less tiring work environment.
(Tilt: up 35˚/down 5˚, Swivel: 344˚, Adjustable height: 145 mm (Tilt: 35°), 155 mm (Tilt: 0°))
• Supports portrait format
• The provided Color Management Software “ColorNavigator 6” enables you to calibrate monitor characteristics and generate color proles
See “1-3. EIZO LCD Utility Disk” (page 11)
• Equipped with a USB Hub function that supports USB 3.0
Achieves high-speed data transfers of up to 5 Gbps, which enables transfers of large amounts of data to and from USB-connected devices in a short amount time.
Also, the “CHARGE” USB downstream port supports quick charging, so you can recharge your smartphone or tablet in a short period of time.
See “6-4. Connecting Multiple External Devices” (page 41) and “USB CHARGE Port” (page 26)
• Displays HDCP (High Bandwidth Digital Protection) protected contents
To Next Page
