Eizo ColorEdge CS2420 User Manual

- 13 -
Chapter 1
Introduction
●
When using digital signal input (HDMI: Video signal
*2
)
Resolution
Vertical scan frequency
24Hz 25Hz 30Hz 50Hz 60Hz
640 x 480 - - - - √
720 × 480 (480i) - - - - √
720 × 480 (480p) - - - - √
720 × 576 (576i) - - - √ -
720 × 576 (576p) - - - √ -
1280 × 720 (720p) - - - √ √
1920 × 1080 (1080i) - - - √ √
1920 × 1080 (1080p) √ √ √ √ √
*2 To display video signals by HDMI signal input, you must change the monitor settings beforehand.
1-5. Setting the Resolution
If the resolution is incorrect after connecting the monitor to a PC or if you want to change the resolution, follow the procedure below.
●
Windows 10
1. Right-click the mouse anywhere on the desktop except on icons.
2. From the displayed menu, click “Display Settings”.
3. On the “Customize your display” dialog box, click “Advanced display settings”.
4. Select a monitor, then choose a resolution from the “Resolution” pull-down menu.
5. Click the “Apply” button.
6. When a conrmation dialog box is displayed, click “Keep changes”.

Eizo ColorEdge CS2420 Specifications

General

Screen Size	24.1 inches
Resolution	1920 x 1200
Panel Type	IPS
Aspect Ratio	16:10
Brightness	300 cd/m²
Contrast Ratio	1000:1
Response Time	15 ms (Gray-to-Gray)
Connectivity	DisplayPort, HDMI, DVI-D
Color Gamut Coverage	99% Adobe RGB
Calibration	Hardware Calibration
Stand Adjustments	Height, Tilt, Swivel, Pivot
Color Support	1.07 billion colors
Viewing Angles	178° horizontal / 178° vertical
USB Ports	2 x USB 3.0 downstream, 1 x USB 3.0 upstream
