Eizo CuratOR EX2721 User Manual

16
Chapter 2 Advanced Adjustments / Settings
GPI Setup
Sets the functions assigned to each pin of the GPI terminals (GPI1 to GPI8).
Setting Description
PIP Switches between dual screen (P in P) and single screen.
POP Switches between dual screen (P out P) and single screen.
Display Direction Rotates or ips screen.
Display Direction
Rotates or ips the main screen.
Display Direction
Rotates or ips the subscreen.
Window Mode Switches the setting values of “Window Cong” - “Window Mode” in sequence.
Input VIDEO
Switches the main screen input signal to VIDEO.
Input S VIDEO
Switches the main screen input signal to S VIDEO.
Input RGB/YP
B
P
R
Switches the main screen input signal to RGB/YP
B
R
R
Input DVI-D 1
Switches the main screen input signal to DVI-D 1.
Input DVI-D 2
Switches the main screen input signal to DVI-D 2.
Input SDI
Switches the main screen input signal to SDI.
Input VIDEO
Switches the subscreen input signal to VIDEO.
Input S VIDEO
Switches the subscreen input signal to S VIDEO.
Input RGB/YP
B
P
R
Switches the subscreen input signal to RGB/YP
B
R
R
Input DVI-D 1
Switches the subscreen input signal to DVI-D 1.
Input DVI-D 2
Switches the subscreen input signal to DVI-D 2.
Input SDI
Switches the subscreen input signal to SDI.
Sync. Select RGB Switches the setting values of “Input Cong” - “Sync. Select RGB” in sequence.
Red Tally
Sets
(red) displayed at the top center of the screen to On or Off.
Green Tally
Sets
(green) displayed at the top center of the screen to On or Off.
WINDOW SELECT Switches the screen performing the operation
Undef Not set.
Notes
• The GPI is an edge operation, without the exception of the “Red Tally” and “Green Tally”. Set pins from open
to the same potential as GND to process operations. Edge operations require a period of at least 200 ms,
with the same potential as GND. After the operation, cancel the equipotentiality with GND.
