33
Chapter 5 Reference
Dimensions
(Width) ×
(Height) ×
(Depth)
Main unit (including
Height adjustable stand)
566 mm (22.3 inch) × 456 - 538 mm (18.0 - 21.2 inch) × 208.5 mm
(8.2 inch)
Main unit (including EZ-
UP stand)
566 mm (22.3 inch) × 380.4 - 533.5 mm (15.0 - 21.0 inch) × 279.9 mm -
307.6 mm (11.0 - 12.1 inch)
Main unit (including
FlexStand)
566 mm (22.3 inch) × 381.5 - 538.5 mm (15.0 - 21.2 inch) × 242 - 256 mm
(9.5 - 10.1 inch)
Main unit (without stand) 566 mm (22.3 inch) × 367 mm (14.4 inch) × 85 mm (3.35 inch)
Mass Main unit (including
Height adjustable stand)
Approx. 10.2 kg (22.5 lbs.)
Main unit (including EZ-
UP stand)
Approx. 12 kg (26.5 Ibs.)
Main unit (including
FlexStand)
Approx. 10.2 kg (22.5 Ibs.)
Main unit (without stand) Approx. 7.2 kg (15.9 lbs.)
Movable range Height adjustable stand Tilt: 40° Up, 0° Down
Swivel: 35° Right, 35° Left
Adjustable height: 82 mm (3.2 inch)
Rotation: 90° (clockwise)
EZ-UP stand Tilt: 25° Up, 0° Down
Swivel: 172° Right, 172° Left
Adjustable height: 153.1 mm (6.0 inch)
Rotation: 90° (clockwise)
FlexStand Tilt: 30° Up, 0° Down
Swivel: 172° Right, 172° Left
Adjustable height: 225 mm (8.9 inch) (157 mm (6.2 inch) when Tilt is 0°)
Rotation: 90° (clockwise)
Environmental
Conditions
Temperature Operating temperature: 5 °C - 35 °C (41 °F - 95 °F)
Storage temperature: -20 °C - 60 °C (-4 °F - 140 °F)
Humidity Operating humidity: 30% - 80% R.H. (no condensation)
Storage humidity: 30% - 80% R.H. (no condensation)
Pressure Operating: 700 to 1,060 hPa
Storage: 200 to 1,060 hPa
