37
Chapter 5 Reference
Mass Main unit (including
Height adjustable stand)
Approx. 9.6 kg (21.2 lbs.)
Main unit (including EZ-
UP stand)
Approx. 11.4 kg (25.1 Ibs.)
Main unit (includeing
FlexStand)
Approx. 9.6 kg (21.2 Ibs.)
Main unit (without stand) Approx. 6.6 kg (14.6 lbs.)
Movable range Height adjustable stand Tilt: 40° Up, 0° Down
Swivel: 35° Right, 35° Left
Adjustable height: 82 mm (3.2 inch)
Rotation: 90° (clockwise)
EZ-UP stand Tilt: 25° Up, 0° Down
Swivel: 172° Right, 172° Left
Adjustable height: 165 mm (6.5 inch)
Rotation: 90° (clockwise)
FlexStand
Tilt: 30° Up, 0° Down
Swivel: 172° Right, 172° Left
Adjustable height: 225 mm (8.9 inch) (Tilt 0°: 174mm (6.9 inch))
Rotation: 90° (clockwise)
Environmental
Conditions
Temperature Operating temperature: 5 °C - 35 °C (41 °F - 95 °F)
Storage temperature: -20 °C - 60 °C (-4 °F - 140 °F)
Humidity Operating humidity: 20% - 80% R.H. (no condensation)
Storage humidity: 10% - 80% R.H. (no condensation)
Pressure Operating: 700 to 1,060 hPa
Storage: 200 to 1,060 hPa
USB Standard USB Specication Revision 2.0
Port Upstream port × 1, Downstream port × 2
Supply current Downstream: Max. 500mA/1 port
S2243W
LCD Panel 22.0-inch (560 mm) TFT color LCD with anti-glare hard coating
Viewing angle: Horizontal 178°, Vertical 178° (CR:10 or more)
Dot Pitch 0.247 mm
Horizontal Scan Frequency Analog: 31-94 kHz
Digital (DVI-D/DisplayPort) : 31-76 kHz
Vertical Scan Frequency Analog: 55-76 Hz (Non-interlace)
(1920 × 1200: 55-61 Hz)
Digital (DVI-D/DisplayPort) : 59-61 Hz (Non-interlace)
(VGA TEXT: 69-71 Hz)
Resolution 1920 dots × 1200 lines
Max. Dot Clock Analog: 202.5 MHz
Digital (DVI-D/DisplayPort) : 162 MHz
Max. Display Color Approx. 16.77 million colors (1064.33 million colors/10bit LUT)
Display Area (H × V) 473.8 mm × 296.1 mm
Power Supply 100-120 VAC ±10%, 50/60Hz 0.85A
200-240 VAC ±10%, 50/60Hz 0.43A
To Next Page
