Eizo FLEXSCAN S2233W User Manual

9
Chapter 1 Features and Overview
1-3 CompatibleResolutions/Frequencies
The monitor supports the following resolutions.
AnalogInput(D-Sub)
Resolution Frequency Mode
S2233W S2243W
DotClock~150MHz DotClock~202.5MHz
640 × 480 ~75 Hz VGA, VESA
√ √
720 × 400 70 Hz VGA TEXT
√ √
800 × 600 ~75 Hz VESA
√ √
1024 × 768 ~75 Hz VESA
√ √
1152 × 864 75 Hz VESA
√ √
1280 × 960 60 Hz VESA
√ √
1280 × 1024 ~75 Hz VESA
√ √
1600 × 1200 ~75 Hz VESA –
√
*
1
*
2
1680 × 1050 60 Hz VESA CVT
√ √
*
1
*
3
1920 × 1200 60 Hz VESA CVT, VESA CVT RB –
√
DigitalInput(DVI-D)
Resolution Frequency Mode
S2233W S2243W
DotClock~120MHz DotClock~162MHz
640 × 480 60 Hz VGA
√ √
720 × 400 70 Hz VGA TEXT
√ √
800 × 600 60 Hz VESA
√ √
1024 × 768 60 Hz VESA
√ √
1280 × 960 60 Hz VESA
√ √
1280 × 1024 60 Hz VESA
√ √
1600 × 1200 60 Hz VESA –
√
*
1
1680 × 1050 60 Hz VESA CVT –
√
*
1
*
2
1680 × 1050 60 Hz VESA CVT RB
√ √
*
1
*
3
1920 × 1200 60 Hz VESA CVT RB –
√
DigitalInput(DisplayPort)
Resolution Frequency Mode
S2233W S2243W
DotClock~120MHz DotClock~162MHz
640 × 480 60 Hz VGA, CEA
√ √
720 × 400 70 Hz VGA TEXT
√ √
720 × 400 (4:3) 60 Hz CEA
√ √
720 × 400 (16:9) 60 Hz CEA
√ √
800 × 600 60 Hz VESA
√ √
1024 × 768 60 Hz VESA
√ √
1280 × 720 60 Hz CEA
√ √
1280 × 960 60 Hz VESA
√ √
1280 × 1024 60 Hz VESA
√ √
1600 × 1200 60 Hz VESA –
√
*
1
1680 × 1050 60 Hz VESA CVT –
√
*
1
*
2
1680 × 1050 60 Hz VESA CVT RB
√ √
*
1
*
3
1920 × 1200 60 Hz VESA CVT RB –
√
*
1
When displaying the wide format input signal, a graphics board in conformance with VESA CVT standard is required.
*
2
Recommended resolution (S2233W: Set this resolution)
*
3
Recommended resolution (S2243W: Set this resolution)
